Main features
1.Maximum place rate can be 4000-5000 per hour
2. Minimum component size can be 0201
3. High-Definition computer vision camera of top and down view
4. 50.-60 feeders can be put on PX4700
5. Automatic identify anchor point
6. Load CAD files directly or visual programming
7. Dispenser with automatically change suction nozzle function can be choosed
8. High cost performance :suit for small and medium enterprises , research centre and so on
Technical parameters
1. 抬放头amount:2-4
2. Maximum place rate: 4000-5000 per hour
3. Feeder amount: 50-60
4. IC disk: 1
5. Component size: Can place all kinds of components equip with suction nozzle.
6. Resolution: 0.008mm
7. Rotation Resolution:0.045
8. Program:Visual aided programming, keyboard entry,CAD data transform
9. Repetition precision: ±0.05mm
10. Component pickup: Induction, Intelligent optical centering, pneumatic
11. External measurement: 1200×1300×1600mm
12.Working area: 800×500mm
13.Weight: 115kg
14 Electrical source: 110V/220V
15. Air pressure: 60psi(0.0445mpa)
16.Power: 750W
Standard Configuration
1.Three cameras (Top, Bottom and side)
2.Pedestal 1set
3.Control box
4.Operational software
5.Vision system
|
